Standard Subliner and Balancer Dimensions
Basic
Style
Standard Subliner and
Balancer Dimensions
A
B
C
D
E
F
G
H
I
J
K
L
M
N
1
.4375
.440
9/16
5/16
5/32
5/16
15/32
1/4-20
3/4
1
5/8
1/2
1/8
2-1/2
2
.500
.5025
11/16
3/8
3/16
5/16
1/2
1/4-20
1
1-1/8
11/16
1/2
3/16
3
3
.5625
.565
3/4
7/!6
7/32
3/8
19/32
5/16-18
1
1-1/8
3/4
5/8
1/4
3-1/2
4
.625
.6275
13/16
1/2
1/4
3/8
5/8
3/8-16
1
1-1/8
13/16
3/4
1/4
4
5
.750
.7525
15/16
1/2
1/4
7/16
11/16
3/8-16
1
1-1/8
15/16
3/4
5/16
4-1/2
Specials
To order
non-standard pins, indicate BASIC STYLE (based on 'A' Dimension) on the
order form below. Use print to indicate ONLY those dimensions which vary
from the standard specifications reflected above.
